There are two optical designs in the Takumar 105/2.8 series. The older one is 4 elements in 4 groups (Takumer Pre-set I, Auto-Takumar). The later one is 4 elements in 4 groups (Takumar Pre-set II, Super-Takumar, S-M-C Takumar, and Pentax K 105/2.8).
I have both types: the Auto-Takumar 105/2.8 (4/4 design) and the Takumar Pre-Set II (5/4 design).
I wanted to compare them to see if the older 4/4 design is better, as is sometimes said?
I expected to find a small difference between images taken with the lenses. But the difference is noticeable when you compare images side by side.
The 4/4 design lens has a slightly wider angle of view than the 5/4 design lens. And the 4/4 design lens has a barrel distortion, while the 5/4 design lens has a pincushion distortion.
1. 4/4 design:
5/4 design:
2. 4/4 design:
5/4 design:
3. 4/4 design:
5/4 design:
I usually prefer a wider angle for the same focal length. But the pincushion distortion of the 5/4 design may be better for real-world photography.
Also, when using a lens with an adapter, the preset aperture control is more convenient than the direct aperture control of Auto-Takumar. Especially when shooting movies.
